12V SPST DIL Reed Relay
- Cat No:
- SY4032
In Stock
$4.75
Description
They will fit into a 14 pin IC socket, are highly sensitive and can be driven by TTL, etc. SPST normally open. Nominal Voltage: 12V
Features:
- Must Op: 9.00VDC
- Must Release: 0.8VDC
- Contact Voltage: 25max
Specifications
- Device Type
- Reed Relay
- Input
- DC
- Contact format
- SPST
- Nominal Voltage
- 12.0V
- Pickup Voltage
- 9.0V
- Dropout Voltage
- 1.0V
- Coil Resistance
- 1000.0Ω
- Coil Current
- 12.0mA
- DC Contact Voltage
- 12.0V
- DC Switching Current (Opening)
- 12.0A
- DC Voltage
- 12.0V
- DC Current Draw
- 12.0A
- Packaged Dimensions
- 1.8cm(Length) x 1.0cm(Width) x 1.0cm(Height)
