Digitech
Analogue Movement Multimeter
- Cat No:
- QM1020
In Stock
$35.95
Description
Digital multimeters have almost completely taken over, but there are those who prefer to use the old analog meter. This well-made meter has audible continuity, in addition to the normal set of functions.
Features:
-Audible continuity
-Specifications
-Display Analogue
-Security class Cat II 1000V
-Basic DCV accuracy 3%
-Ave/RMS AVE
-Input impedance 10M
-Special features dB, continuity buzzer
Specifications
- DC Current Ranges
- 50.0µA,2.0mA,25.0mA,250.0mA
- DC Current Accuracy
- 3.0%
- Resistance Ranges
- 2.0kΩ,20.0kΩ,200.0kΩ,2.0MΩ,20.0Ω
- Resistance Accuracy
- 3.0%
- AC Voltage Ranges
- 10.0V,50.0V,250.0V,1000.0V
- AC Voltage Accuracy
- 4.0%
- DC Voltage Ranges
- 100.0mV,500.0mV,2.0V,10.0V,50.0V,250.0V,1000.0V
- DC Voltage Accuracy
- 3.0%
- Length
- 150.0mm
- Width
- 100.0mm
- Depth
- 35.0mm
- Packaged Dimensions
- 17.4cm(Length) x 13.8cm(Width) x 6.3cm(Height)
